SUMMIT 8800 REPORTING 07
Manually via the print jobs screen at the SUMMIT 8800
Show on print menu
Click if the job must be show in print menu of the main menu for manual
trigger
On interval, to print the job at a regular time intervals
Print every
Select the interval between two reports from the list
Print interval offset Delaying a print by the offset time to prevent 2 Summits printing at the same
time.
On change of state of a variable
Print on change of
Select the variable ID from the list. Care should be taken when selecting the ID
as a print will be generated on each change in state.
On an event, like a fault or alarm
Event variables
Tick on the ID tree one or more boxes on which the event print should occur.
7 .1 .3 Configure report
To start making the actual content of the report press configure report:
Figure 120 Configure reports
On the right hand side there is the report which will normally be blank for a new report. Now it
is possible to drag items from the variable tree on the left hand side to create a report as shown.
Items can come from the real-time variables or from the data log and may include alarm and
audit data:
