KROHNE Summit 8800 Vol 3 - Manual (Page 41)

41 www.krohne.com
08/2013 - MA SUMMIT 8800 Vol3 R02 en
SUMMIT 8800 DISPLAY & WEB ACCESS 06
6 .3 .1 Main menu & submenus
The top part of the display page defines the main menu and its submenus. They appear unmodi-
fied on the Summit display:
Figure 31 Configurator main menu & submenu
Figure 32 Display main menu & submenu
Both the main menu and submenu have several functions associated with it to modify the menu:
Make a new menu item Press the new (sub)menu button
Move a menu item On a menu, click and hold the left mouse button and drag it to another
location
Delete a menu item Press the delete key at the menu item or press the del button
Change a menu name Click the menu name or press edit , select the menu item and click the
name.
Change a menu bitmap Click the menu bitmap or press edit, select the menu item and press edit.
Delete a menu bitmap Press edit, select the menu item and press delete.
