SUMMIT 8800 REPORTING 07
Bold/ italic/ underline Click to set the modifier
Size/ colour Select the font size and colour
Figure 142 Select log data from a list
Log data:
Logged ID
Select the variable from a log to be added
Log records and order Provide the record number and define if it the number counts with the oldest
or newest first
Hide name/ value/ units From the variable to be added, click the box if this part is not needed
Custom format Click the box for a special format with the number of digits after and before
the decimal point
Bold/ italic/ underline Click to set the modifier
Size/ colour Select the font size and colour
Figure 143 Select alarm log data
Alarm log data
Show items
Click if the on and off time, the type and state of the alarm from an alarm
record must be shown
Records to show/ order Define the number of records to be shown counting with the oldest or
newest first
Font size Select the font size
