SUMMIT 8800 GENERAL INFORMATION 09
Figure 218 Min/max ID setting and resulting variables
Select a desired variable from the ID tree and drag and drop it into a min/max ID position. The
Summit will then calculate the minima and maxima for the active variable for each of the follow-
ing periods:
Min ch ID.1 Max ch ID.1 Current hour
Min cd ID.1 Max cd ID.1 Current day
Min cm ID.1 Max cm ID.1 Current month
Min ph ID.1 Max ph ID.1 Previous hour
Min pd ID.1 Max pd ID.1 Previous day
Min pm ID.1 Max pm ID.1 Previous month
These ID’s are in the active list and can be used in display, reports and communication.
The min/max ID’s in the preset list are strings with the ID names associated to the min/max
value.
The setting for an item can be cleared by pushing the associated clear button
