2.7GHz Spectrum Analyzer Operation Manual
⎯ ⎯
95
Trigger
Mode
Source
Setting
Continuous, Single
Video, External (0~5V rising edge)
Trigger delay, Trigger Frequency
Display Contrast, Backlight ON/OFF, Invert Screen.
Split Window: Upper and Lower
Save/Recall 100 traces and Setup
Calendar and clock
Interface
RS232C
Cal Signal 100MHz, -30dBm
Display: 640 × 480 high resolution graphical LCD, B&W
Weight: 4.5kg without options
General
Size 330 (W) × 170(H) × 340(D) mm
Options
Opt.01 Frequency Range 9kHz to 2.7GHz
Tracking Amplitude Range -50dBm to 0 dBm
Generator Amplitude accuracy ±1dB @100MHz, 0dBm
Amplitude flatness ±1.5dB @0dBm
Harmonics <-30dBc
Reverse Power +30dBm
Impedance 50 Ohm nominal
Return Loss <1.5:1
Opt.02
DC/AC/Battery Power Supply
Operation and battery pack
AC 100 to 240V, DC-12V and 10.8V Li Ion battery pack
Opt. 03 ±1ppm Stability ± 1ppm 0~50°C, ±1ppm / year
Opt.06 GPIB interface IEEE 488 bus
Opt. 07 Soft Carrying Case GSC-001
Opt. 08 General Kit set
ADP-002: SMA (J/F) to N (P/M) adaptor × 2
ATN-100: 10dB Attenuator × 1
GTL-303: RF Cable assembly(RD316 + SMA(P) ×2, 60cm ) ×2
GSC-002: Kit box
× 1
Opt. 09 CATV Kit set
ADP-001: BNC (J/F) to N (P/M) adaptor × 2
ADP-101: BNC (P/M) 50Ω to BNC (J/F) 75Ω adaptor × 2
GTL-304: RF Cable assembly ( RG223, N(P)-N(J), 30cm ) × 2
GSC-003: Kit box × 1
Opt. 10 RLB Kit set
GAK-001: Cal. Kit, termination, N, 50Ω × 1
GAK-002: Cap with chain × 1
GTL-302: RF Cable assembly ( RG223 + N (P) × 2, 30cm ) × 2
GSC-004: Kit box × 1
Opt. 11 DC Power line GTL-401: DC power cord with DC jack and lighter plug,
5A.
Opt. 12 EMI Filters(*) RBW Selections: 9kHz and 120kHz, 6dB bandwidth,
RBW Accuracy: 15%
Opt. 13 Demodulator(*) Demodulator: AM, FM
Output: Internal speaker, 3.5mm stereo jack wired for
mono operation.
Opt. 14 EMI filters and 300Hz RBW(*) RBW Selections: 9kHz and 120kHz, 6dB bandwidth,
300Hz, 3dB bandwidth
RBW Accuracy: 15%
