2.7GHz Spectrum Analyzer Operation Manual

91

Demodulation, FM

Push FM ON OFF can switch the FM ON or OFF.

Demodulation, AM

Push AM ON OFF can switch the AM ON or OFF.

Demodulation, Speaker

Push SPK ON OFF can switch the speaker ON or OFF.

Volume and Squelch Control

The volume and squelch can be set from 0 to 255 and 0 to 750 respectively.

External Reference Frequency

UP/DOWN and Scroll: To select the external reference frequency in use.

Option

Demod

FM

On Off

Option

Demod

AM

On Off

Option

Demod

Volume

0

1

2

3

7

6

5

4

8

9

.

-
