2.7GHz Spectrum Analyzer Operation Manual

67

Adjacent Channel Offset 1(2)

Channel UP

The Power Measurement will measure the next higher channel.

Channel Down

The Power Measurement will measure the lower channel.

1

Start:99.5MHz

RBW:30 kHz

Stop:100.5MHz

VBW:100 kHz

Center:100.0MHz
Span:1.0MHz

Sweep:100.0ms

OFFSET:100 kHz

Ref

Lvl: -30.0 dBm

-30.0

-40.0

-50.0

-60.0

-70.0

-80.0

-90.0

-110.0

-100.0

SAT JAN 28, 2003

14:30:25

INT:REF

AMPL CAL

Power Measurement

ACPR

LACPR UACPR

1: -41.42 -40.56 dB

2: -35.62 -34.58 dB

OCBW:205 kHz

Power:-30.2dBm

Adj CH

BW 1

Adj CH

Offs 1

Return

Adj CH

BW 2

Adj CH

Offs 2

Pwr Measure

0

1

2

3

7

6

5

4

8

9

.

-

GHz

dBm

MHz

dBmV

kHz

dBuV

BK SP

ADJ CH

Offs 1

Setup

ADJ CH

OFFSET

ADJ CH

Offs 2
