2.7GHz Spectrum Analyzer Operation Manual
⎯ ⎯
15
6.0 Quick use guide
6.1 General Description
The quick use guide provides the information of measurement-oriented operation. Every
operation is titled with a measurement demand and followed by the corresponding operation
sequence of the keys on the front panel and terminals on the rear panel.
6.2 Guide
6.2.1 Find the signal
(1) The frequency is unknown: Use Full Span to scan entire frequency range.
Function key Description
Span Select the Span functions.
F4 Select the Full Span to scan the entire measuring band.
(2) The frequency is known: Specify the frequency directly.
Function key Description
Frequency Select the Frequency functions.
F1
Specify the Center Frequency.
N, … , MHz
Key in the specific frequency by using numerical and unit
keys.
Span
Activate the Span to set the frequency range.
M, … , MHz Key in the frequency range or
Spinner Rotate Spinner to change the Span in 1-2-5 sequence.
Or set the start/ stop frequency.
Function key Description
Frequency
Select the Frequency functions.
F2
Specify the Center Frequency.
N, … , MHz
Key in the specific frequency by using numerical and unit
keys.
F3 Activate the Span to set the frequency range.
M, … , MHz Key in the frequency range.
6.2.2 Find Peak signal
(1) In Frequency function
Function key Description
F5
Center>
Set the Center frequency to the peak signal frequency, so
that the peak signal will be shown at up right of the
central display.
