2.7GHz Spectrum Analyzer Operation Manual
⎯ ⎯
94
9.0 Specification
Item Specification
Frequency
Range 9kHz-2.7GHz
Accuracy see time base
Span Accuracy see time base
Span Range 2kHz to 2.5GHz in 1/2/5 sequence, full span, zero span
Phase Noise -85dBc/Hz typical @ 1GHz 20kHz Offset
Time Base ± 10ppm, 0-50C, 5ppm/yr
Bandwidth RBW Selections 3kHz, 30kHz, 300kHz, 4MHz,
RBW Accuracy 15%
Video Bandwidth 10Hz to 1MHz in 1-3 steps
Sweep time 50 ms to 12.8 s
Amplitude Input Range -100dBm to +20dBm, 1M to 2.5GHz @3k RBW
-95dBm to +20dBm, 2.5G to 2.7GHz @3k RBW
-75dBm to +20dBm, 150k to 1MHz @3k RBW,
-65dBm to +20dBm 50k to 150kHz @3k RBW
Reference Level Range -30 to +20dBm, overload protected
Accuracy
± 1.5dB @100MHz
Frequency Flatness ±1.5dB,
Display Range Linearity ± 1.5dB over 70dB
Overload protection +30dBm, ±25VDC
Average Noise Floor -100dBm, 1MHz to 2.5GHz @3k RBW
-95dBm, 2.5GHz to 2.7GHz @3k RBW
-75dBm, 150kHz to 1MHz @3k RBW
-65dBm, 50k to 150kHz @3k RBW
Harmonic Distortion <-60dBc @-40dBm Input
Non-harmonic Spurious <-60dB typical down from Ref. Level 150k to 2.7GHz
Third Intermodulation
<-70dBc @-40dBm Input, 2 MHz apart
Input RF input
Overload Protection +30dBm, ±25VDC
Impedance: 50 Ohm nominal
Return loss <1.5:1 @0dBm Ref. Level
Connector Type N Female
External reference input 1M, 1.544M, 2.048M, 5M, 10M, 10.24M, 13M, 15.36M,
15.4M, 19.2M
Output Reference clock output 10MHz
Features Marker
Mode
Number
Normal and Delta mode
Up to 10 in Multi Marker mode
Peak Search To Peak, To Center, Next Peak, Peak Right, Peak Left
and Peak Track
Trace
Number
Functions
2, Tr A and B for display memory
Peak Hold, Average, Freeze, Math.
Detect: Sample, Peak+, AVG1/2/3, Quasi-peak
Power measurement ACPR × 2, OCBW, Channel power
Limit Line
Number
Function
2, high and low
Edit: Insert, Delete, Undo
Pass/Fail
