Battery cabinet wiring – Edwards Signaling 2400 Series User Manual
Page 76
1
NO T-TAPS
PERMITTED
+
+
+
+
+
+
+
+
INP 1
INP 2
2 ZONE IDC MODULE
4.7K EOL RESISTOR
P/N 46229-0107
0R EOL-P1
STYLE B (CLASS B) 4-WIRE SMOKE DETECTOR WIRING
BATTERY CABINET INSTALLATION
ADDITIONAL CIRCUITS WIRED
SAME AS INP1.
[ALZCPA22.CDR]
03/01/95
AUX
ALARM
TROUBLE
SIG1
SIG2
INP1
INP2
PGM
MODE
+
+
+
+
+
CONTROL PANEL
ALARM
ALARM
ALARM
IN
IN
IN
OUT
OUT
OUT
24 VDC
24 VDC
24 VDC
24 VDC
24 VDC
24 VDC
EOL RELAY
P/N 6254A-003
MOUNTED IN A 4" SQ. BOX
WITH 1 GANG PLASTER RING.
6251B-003 BASE (U.S.)
or
6251C-003 BASE (CAN.)
RELAY SHOWN IN
ENERGIZED STATE
1. ALL WIRING SUPERVISED AND POWER LIMITED.
2. CONFIGURE ZONE AS ALARM ZONE.
3. AUXILIARY POWER MUST BE CONFIGURED TO
TURN OFF DURING RESET.
4. MAXIMUM WIRE RESISTANCE SHOULD NOT
EXCEED 50 OHMS PER CIRCUIT.
NOTES
5 REFER TO APPENDIX FOR COMPATIBLE DEVICES.
6. CURRENT CONSUMPTION OF 4 WIRE
DETECTORS MUST BE INCLUDED IN THE
AUXILIARY POWER ALARM CURRENT
WHEN SELECTING A BATTERY.
7. MAXIMUM INPUT CAPACITANCE 100
f.
m
8. CURRENT CONSUMPTION OF EOL RELAY
MUST BE INCLUDED IN THE AUXILIARY
POWER SUPERVISORY CURRENT WHEN
SELECTING A BATTERY.
7
5
AUX. POWER
24VDC @ 500mA
TOP VIEW
FRONT VIEW
TOP
SIDE VIEW
BOTTOM VIEW
COVER
COVER
BATTERY
BATTERY
ALL KNOCKOUTS
FOR 1/2 OR 3/4" CONDUIT
(1.3 or 1.9 cm)
FINISHED WALL
(SURFACE MOUNT)
FINISHED WALL
(FLUSH MOUNT)
14.
5"
(36.8 cm)
15"
(38.1 cm)
13"
(33 cm)
2.75"
(7 cm)
21.62"(54.9 cm)
22"(55.9 cm)
20.18"(51.3 cm)
1"(2.54 cm)
BATTERY CABINET DIMENSIONS
BATTERY CABINET LOCATION
FIRE ALARM
CONTROL PANEL
BC-2 BATTERY
CABINET
SUGGESTED BATTERY
CABINET LOCATIONS
BATTERY CABINET MUST BE LOCATED
WITHIN 5’ (152 CM) OF FIRE ALARM PANEL
CONDUIT
3" (7.6 CM) MIN.
3" (7.6 CM) MIN.
BC-2 BATTERY
CABINET
BATTERY CABINET WIRING
BLACK (-)
BATTERY LEADS
BATTERY CABINET
CONTROL PANEL
Not to scale
TYRAP STRAIN RELIEF
WIRING: 16 GAUGE
CONDUIT
RED (+)
JUMPER
8A FUSE
(P/N 46097-0110)
BATTERY
BATTERY
