1.1 Components
2412
Two Zone Base Panel w/3 Option Module Expansion Spaces, Gray Enclosure (Cat.# 2412)
Two Zone Base Panel w/3 Option Module Expansion Spaces, Red Enclosure (Cat.# 2412-R)
This panel provides two Class B (Style B) Initiating Device Circuits (IDCs) and two Class B (Style Y)
Indicating Appliance Circuits (IACs). There is space for three option modules. Option modules include a
Relay/City-Tie, Two Zone Initiating Device, a Dialer Module, and Remote Annunciator Driver Modules.
Space for standby batteries is provided in the enclosure. Refer to the Appendix to select the proper battery
for your application.
2414
Four Zone Base Panel w/2 Option Module Expansion Spaces, Gray Enclosure (Cat.# 2414)
Four Zone Base Panel w/2 Option Module Expansion Spaces, Red Enclosure (Cat.# 2414-R)
This panel provides four Class B (Style B) Initiating Device Circuits (IDCs) and two Class B (Style Y)
Indicating Appliance Circuits (IACs). There is space for two option modules. Option modules include a
Relay/City-Tie, Two Zone Initiating Device, a Dialer Module, and Remote Annunciator Driver Modules.
Space for standby batteries is provided in the enclosure. Refer to the Appendix to select the proper battery
for your application.
2418
Eight Zone Base Panel w/3 Option Module Expansion Spaces, Gray enclosure (Cat.# 2418)
Eight Zone Base Panel w/3 Option Module Expansion Spaces, Red enclosure (Cat.# 2418-R)
This panel provides eight Class B (Style B) Initiating Device Circuits (IDCs) and two Class B (Style Y)
Indicating Appliance Circuits (IACs). There is space for three option modules. The available option
modules include a Relay/City-Tie Module, a Dialer Module, and Remote Annunciator Driver Modules.
Space for standby batteries is provided in the enclosure. Refer to the Appendix to select the proper battery
for your application.
Table 1.1 - Base Panel Capacity
Base Panel
Accessory/Option
Module
2412
Panel Capacity:
3 Option Modules
2414
Panel Capacity:
2 Option Modules
2418
Panel Capacity:
3 Option Modules
Internal Batteries Two 12 V @ 4.5 AH
Two 12 V @ 6.5 AH
Two 12 V @ 4.5 AH
Two 12 V @ 6.5 AH Two 12 V @ 4.5 AH
Two 12 V @ 6.5 AH
Four 6 V @ 8.0 AH
External Batteries 2400-BATBOX(R)
2 ea. P/N 12V10,
12 V @ 10 AH
2400-BATBOX(R)
2 ea. P/N 12V10,
12 V @ 10 AH
2400-BATBOX(R)
2 ea. P/N 12V10,
12 V @ 10 AH
2 Zone Initiating Device Circuit
2400-2IDC (P/N 240457)
0
Relay/City-Tie Module
2400-RCT (P/N 240459)
Annunciator Driver Master
Module
2400-ADM (P/N 240461)
Any Combination of 3, Max Any Combination of 2, Max
Any Combination of 3, Max
Dialer Module
2400-DL1 (P/N 240508)
2400-BPA Base Panel Class A (Style D/Z) Converter Module (P/N 46199-1072)
This Class A (Style D/Z) Base Panel Converter changes the base panel to Class A (Style D) Initiating
Device Circuits and Class A (Style Z) Indicating Appliance Circuits. The Class A Base Panel Converter
does NOT require any option module expansion spaces.
