9
4.0 INSTALLATION
4.1 Codes and Standards
Install this panel in accordance with all applicable codes and standards to the satisfaction of the Authority
Having Jurisdiction (AHJ). A partial list of codes and standards appears in the Appendix.
US Installations: For Class B (Style B/Y) circuits, the End-Of-Line resistor is installed on the last device.
Canadian Installations: For Class B (Style B/Y) circuits, purchase End-Of-Line resistor plates separately
from your Distributor. Use the specified resistors and install in a separate electrical box in an accessible
location beyond the last device on a circuit.
4.2 Site Storage
Remove backbox from top of carton. Place extra modules in panel carton and store safely in a dry location
during rough-in, to avoid damage to electronic parts.
4.3 Drawing References
Table 4.1 lists the drawings that are included at the end of this manual.
Table 4.1 - Drawing References
Subject Drawing Title
Assembly Details
Ribbon Connectors
Battery Interconnect Control Panel Installation 1
Control Panel Installation 2
Base Panel Circuits
IAC Wiring Diagram
IAC Wire Chart Control Panel
Initiating Device Circuits
IDC Wire Chart Initiating Device Circuit Wiring
2IDC Two Zone Initiating Device Circuit Module INITIATING DEVICE CIRCUIT WIRING
or see the Installation Sheet supplied with the Two
Zone IDC Module
Relay/City-Tie Module
Applications.
Connections and Jumper Settings Relay/City Tie Module
Control Panel Applications 1
or see the Installation Sheet supplied with the
Relay/City-Tie Module
Remote Annunciators & Annunciator Driver Modules REMOTE ANNUNCIATORS
4-Wire Smoke Detectors Control Panel Applications 2
Class A Wiring CONTROL PANEL
INITIATING DEVICE CIRCUIT WIRING
or see the Installation Sheets supplied with the BPA
Base Panel Class A Converter Module & IDCA, 2IDC
Module Class A Converter
Panel Programming Instructions Panel Programming
Panel Operations Panel Operation
