34
Table 9.1 - Specifications
Base Panel Assemblies
Environment
Relative Humidity
Operating Temperature
85% @ 86°F (30°C)
32°F to 120°F (0°C to 49°C)
Table 9.2 - Specifications
2400-BPA Base Panel Class A (Style D/Z) Converter Module (P/N 46199-1072)
Expansion Space None
IDC Wiring Converts two Style B Circuits into two Style D Circuits
IAC Wiring Converts two Style Y Circuits into two Style Z Circuits
Weight 0.4 lbs (0.18 Kg)
Table 9.3 - Specifications
2400-2IDC IDC Module (P/N 240457)
Expansion Space 1
IDC Zones Two Style B, verification optional
Detector Capacity per IDC Circuit 30 - Photoelectric Smoke
50 - Ionization Smoke
Detector voltage 17.85 to 26.4 VDC.
Max. Ripple = 400 mVDC.
Max. Alarm Current = 33 mADC
Refer to Compatibility Section.
Relay Bases are NOT supported.
IDC EOL 4.7K Ω , 1/2 Watt
Max. Circuit Resistance 50 Ω
Indicators and Controls Trouble LED
Enable/Disable Switch
Weight 0.3 lbs (0.14 Kg)
Table 9.4 - Specifications
2400-IDCA IDC Class A (Style D) Converter Module (P/N 46199-1074)
Expansion Space None
IDC Wiring Two Class A (Style D) Circuits
Weight 0.3 lbs (0.14 Kg)
Table 9.5 - Specifications
2400-RCT Relay/City-Tie Module (P/N 240459)
Expansion Space 1
Configurable Operation Reset, Alarm, Trouble, or Supervisory
Master Box Operation
Max. Wiring Resistance
Trip Current Nominal 24 VDC
25
Ω
200 mA into 14.5 Ω coil
Reverse Polarity Operation
Loop and Receiver Resistance
Current Range Nominal 24 VDC
1.5 K
Ω , Max.
2.5 to 9.9 mA
Dry Contact (Shunt) Normally-Open OR Normally-Closed, 24 VDC @ 1 A
See Application Section for proper installation.
Indicators and Controls Trouble LED
Enable/Disable Switch
Weight 0.4 lbs (0.18 Kg)
