35
Table 9.6 - Specifications
2400-ADM Annunciator Driver Master Module (P/N 240461)
Expansion Space 1
Circuit Rating 30 V @ 15 mA Max.
Weight 0.4 lbs (0.18 Kg)
Table 9.7 - Specifications
2400-ADS Annunciator Driver Slave Module (P/N 240463)
Expansion Space 0
Circuit Rating 30 V @ 15 mA Max.
Weight 0.3 lbs (0.14 Kg)
Table 9.8 - Specifications
Remote Annunciators
Wiring 22 AWG, Min.
Power 24 VDC, Nominal
Model Supervisory Current AlarmCurrent
2400-RTU 10 mA 10 mA
2400-RTU4ZA 11 mA 11 mA + 11 mA/ Active zone LED
2400-RTU8ZA 12 mA 12 mA + 11 mA/ Active zone LED
2400-4ZA 1 mA 1 mA + 11 mA/ Active zone LED
2400-8ZA 2 mA 2 mA + 11 mA/ Active zone LED
(C) = Bilingual version
Table 9.9 - Specifications
2400-BATBOX(R) Battery Cabinet
Wiring 5 Ft (1.52 M) Max. 16 AWG Min.
Battery Type 2 x 12 V, 10 AH, Lead-Acid
Dimensions (HWD)
Back box
Finished
13" x 20.19" x 2.75" [33.0 cm x 51.3 cm x 7.0 cm]
15" x 22" x 1.125" [38.1 cm x 55.9 cm x 2.9 cm]
