19
5.3 Configuring System Timers
1. The configure System Timers step is indicated by the 4-phase flashing green Power LED. The status
of the panel’s Alarm Silence Inhibit Timer is indicated by the zone disabled LED as shown in Table 5.6.
Table 5.6 - Alarm Silence Inhibit Timer Status
Alarm Silence Inhibit Timer Setting Zone Disabled LED
Disabled OFF
1 Minute Y PAUSE Y PAUSE YY ..
2 Minutes YY PAUSE YY PAUSE YY ...
3 Minutes YYY PAUSE YYY PAUSE YYY ...
2. Use the TROUBLE SILENCE switch to select between the four states. The status of the panel’s automatic
Alarm Silence Timer is indicated by the alarm silenced LED as shown in Table 5.7.
Table 5.7 - Automatic Alarm Silence Timer Status
Timer setting Alarm Silenced LED
No timer OFF
10 Minutes Y PAUSE Y PAUSE Y ...
20 Minutes YY PAUSE YY PAUSE Y Y...
30 Minutes YYY PAUSE YYY PAUSE YYY ...
3. Use the ALARM SILENCE switch to toggle between the four states.
4. When the proper LED combination is displayed, press the RESET switch; the panel is now ready to
program Auxiliary Power.
5.4 Programming Auxiliary Power
1. The program Auxiliary Power step is indicated by the 5-phase flashing green Power LED. Use the
ALARM SILENCE switch to program the auxiliary power as shown in Table 5.8.
Table 5.8 - Auxiliary Power on Reset Status
Auxiliary Power Alarm Silenced LED
Remains energized during reset OFF
De-energize on reset
(alarm, verification, & test modes) Y PAUSE Y PAUSE Y ...
2. Use the ALARM SILENCE switch to toggle between the two states.
3. Press the RESET switch to return to the automatic module configuration step (1-phase flash), where the
programming process started. You may modify any panel configuration by repeating the programming
cycle.
To exit the programming mode, return the PROGRAMMING MODE switch to the OFF (down) position. The
panel should return to the Normal mode. You may exit the Programming mode at any time. This is useful
when changing only one system parameter.
