EMO‐3000
Operation and Programming Manual
25
Use F2 to page through the General A menu to access all variables. Use the following procedure to
change a value:
F2 Use page up to move the variable up to a position next to the printer.
F4 Allows programming.
4146 You only need to enter the pass code once for multiple changes. Enter new digits from left to
right. Further prompts appear at the foot of the display.
F3 = PID VARIABLES
PID VARIABLES *** CH=XXX
‐‐‐> PID PROPORT. = XXXXX.
PID INTEGRAL = XXXXX.
PID DERIVATIV = XXXXX.
PID TOLERANCE = XXXX.X
PID DELTA STEP = XXXX.X
PID INIT. KICK = XXXXX
F1=ESC F2=PGUP F3=PGDN F4=PRGM
Access additional variables using F2 or F3.
When the desired variable moves to the arrow, select F4 = PROGRAM. The DM‐3000 then asks for the
pass code.
ENTER PASS CODE = XXXX
The code is 4146.
Key in the correct value and Enter with F6.
F4 = GENERAL B
* * * B CHANNEL VARIABLES * CH = XXX
‐‐‐‐> KFR ‐ FACTOR B = XXXX.X
RATE B UNITS = ??
KFT ‐FACTOR B = XXXXX.
TOTAL B UNITS = ??
SAMPLES FOR B = XXXXX.
CUTOFF FRE. B = XXXX.X
F1 = ESC F2 = PGUP F3 = PGDN F4 = PRGM
When the desired variable moves to the arrow, select F4 = PROGRAM. The DM‐3000 then asks for the
pass code.
