EMO‐3000

Operation and Programming Manual

SINGLE CHANNEL DISPLAY 3 ‐ PID VARIABLES

P I D MODE

DSP 03 FLU = 00

CHANNEL = XX

GAIN

= XXXX.

mA SCALER = XXXXX.

TOLERANCE

= XXXX.

KFR FACTR = XXXXX.

I‐KICK

= XXXX.

I‐PART = XXXXX.

MA OFFSET

= XX.XX

D‐PART = XXXXX.

SAMPLE AM

= XXXXX.

CUTOFF = XXXXX.

DELAY

XXX.XX

DELTA STP = XXXXX.

F1=ESC

F2 = FLU UP

F3 = FLU DN

F4 = RES

F5 = D+

 F2 pages UP through the Fluid Numbers.
 F3 pages DOWN through the Fluid Numbers.
 F5 calls up the fourth channel screen for PID Mode.

SINGLE CHANNEL DISPLAY 4 ‐ PID FLUID TABLES

This display screen shows 10 closed loop set points and 10 corresponding mA values. They are the
Scratch Pad Values in the Fluid Tables.

P I D MODE

DSP 04

FLU = 00

CHANNEL = XX

__SET_POINT_!_MA’s_!__SET_POINT_!_MA’s_!

XXXXX. .03.99

F1=ESC

F2 = FLU UP

F3 = FLU DN

F4 = RES

F5 = D+

 F2 pages UP through the Fluid Numbers.
 F3 pages DOWN through the Fluid Numbers.
 F4 resets the Scratch Pad Values for the selected Fluid Number.
 F5 returns to the PID Single Channel Display 1.

This display is NOT available in Monitor Mode.
