Auto Selection Default Tables
63
9.0
Auto Selection Default Tables
Auto Selection (Gage) Default Table
Parameter
3 PSIG
10 PSIG
15 PSIG
25 PSIG
50 PSIG
100 PSIG
250 PSIG
500 PSIG
CAPACITY
3
10
15
25
50
100
250
500
CT-BY
0.0005
0.001
0.002
0.002
0.005
0.01
0.02
0.05
UNITS (Cal)
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
TYPE
GAGE
GAGE
GAGE
GAGE
GAGE
GAGE
GAGE
GAGE
CAL SPAN 1
0.3
1
1.5
2.5
5
10
25
50
CAL SPAN 2
0.6
2
3.0
5.0
10
20
50
100
CAL SPAN 3
0.9
3
4.5
7.5
15
30
75
150
CAL SPAN 4
1.2
4
6.0
10.0
20
40
100
200
CAL SPAN 5
1.5
5
7.5
12.5
25
50
125
250
CAL SPAN 6
1.8
6
9.0
15.0
30
60
150
300
CAL SPAN 7
2.1
7
10.5
17.5
35
70
175
350
CAL SPAN 8
2.4
8
12
20.5
40
80
200
400
CAL SPAN 9
2.7
9
13.5
22.5
45
90
225
450
CAL SPAN 10
3.0
10
15
25.0
50
100
250
500
HYSTERESIS
1.5
5
7.5
12.5
25
50
125
250
FILTR
5
5
5
5
5
5
5
5
DSP/SEC
3
3
3
3
3
3
3
3
ZERO %
2
2
2
2
2
2
2
2
ZERO+/-%
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
AZM +/-
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
MOTION
1
1
1
1
1
1
1
1
MIN PRES
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
MAX PRES
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
PSI
ON
ON
ON
ON
ON
ON
ON
ON
KPa
ON
ON
ON
ON
ON
ON
ON
ON
mmHg0
•
C
ON
ON
ON
ON
ON
ON
ON
ON
BAR
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
inHg0
•
C
ON
ON
ON
ON
ON
ON
ON
ON
mBAR
ON
ON
ON
ON
ON
ON
ON
ON
cmH
2
0
ON
ON
ON
ON
ON
ON
ON
ON
kg/cm
2
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
inH
2
060
•
F
ON
ON
ON
ON
ON
ON
ON
ON
inH
2
04
•
C
ON
ON
ON
ON
ON
ON
ON
ON
ftseaH
2
0
ON
ON
ON
ON
ON
ON
ON
ON
TORR
ON
ON
ON
ON
ON
ON
ON
ON
metrsH
2
0
ON
ON
ON
ON
ON
ON
ON
ON
PASCAL
ON
ON
ON
ON
ON
OFF
OFF
OFF
mmH
2
04
º
C
ON
ON
ON
ON
ON
ON
ON
ON
Table 9-1. Auto Selection (Gage) Default Table (3 PSIG – 500 PSIG)
