5.13.4 Port 1 RS485 Menu
Table 5-16 outlines the parameters of the Port 1 RS485 menu.
5.13.5 Port 1 Simplex Menu
Table 5-17 outlines the parameters of the Port 1 Simplex menu.
LED Display Alpha-Numeric Display Key Pressed Remarks
PORT 1 RS485 DOWN arrow Enters RS485 menu
ADDR 1 UP or DOWN
arrow
Press LEFT or RIGHT arrow keys to
change the current state of the selection.
See Section 5.7 on page 19
CHECK NONE Press LEFT or RIGHT arrow keys to
change the current state of the selection.
NONE, XOR or CHECKSUM
RESP ACK/NAK Press LEFT or RIGHT arrow keys to
change the current state of the selection.
ECHO, ACK/NAK or NONE
PORT 1 EXIT ? YES key Return to menu SET-UP/PORT 1 ?. See
Table 5-10 on page 24.
NO key Return to menu PORT 1/DUPLEX. See
Table 5-14 on page 26.
Table 5-16. Port 1 RS485 Menu
LED Display Alpha-Numeric Display Key Pressed Remarks
PORT 1 SIMPLEX DOWN arrow Enters Simplex menu
SET P1 AUTO SI? YES key Press LEFT or RIGHT arrow keys to
change the current state of the selection.
SIMPLX 1?, SMPLX 2?, SMPLX 3? or
SMPLX 4?
NO key Continue to BAUD/9600
BAUD 9600 UP or DOWN
arrow
Press LEFT or RIGHT arrow keys to
change the current state of the selection.
1200, 2400, 4800, 9600 or 19200
PARITY EVEN Press LEFT or RIGHT arrow keys to
change the current state of the selection.
EVEN, ODD, MARK or NONE
PORT 1 STANDARD Press LEFT or RIGHT arrow keys to
change the current state of the selection.
STANDARD, MODIFY or CUSTOM
PORT 1 MODIFY See Table 5-16 on page 28
PORT 1 CUSTOM Allocated for future use
PORT 1 EXIT ? YES key Return to menu SET-UP/PORT 1 ?. See
Table 5-10 on page 24.
NO key Return to PORT 1/SIMPLEX
Table 5-17. Port 1 Simplex Parameters
