26 DLR3110 Rack Mount Digital Pressure Calibrator Manual
5.13.3 Port 1 Duplex Menu
Table 5-14 outlines the parameters of the Port 1 Duplex menu.
LED Display Alpha-Numeric Display Key Pressed Remarks
PORT 1 DUPLEX DOWN arrow Enters Duplex menu
SET P1 AUTO DU? YES key Enters AUTO DU? menu. Press LEFT or
RIGHT arrow keys to change the current
state of the selection. DUPLEX 1?, DUPLEX
2?, DUPLEX 3? or DUPLEX 4?
NO key Continue to BAUD/9600
BAUD 9600 UP or DOWN
arrow
Press LEFT or RIGHT arrow keys to change
the current state of the selection.
1200, 2400, 4800, 9600 or 19200
PARITY EVEN Press LEFT or RIGHT arrow keys to change
the current state of the selection.
EVEN, ODD or MARK
PORT 1 STANDARD Press LEFT or RIGHT arrow keys to change
the current state of the selection.
STANDARD, MODIFY, RS-485 or CUSTOM
PORT 1 MODIFY See Table 5-15 on page 27
PORT 1 RS-485 See Table 5-16 on page 28
PORT 1 CUSTOM Allocated for future use
PORT 1 EXIT ? YES key Return to menu SET-UP/PORT 1 ?. See
Table 5-11 on page 24.
NO key Return to PORT 1/DUPLEX
Table 5-14. Port 1 Duplex Menu
