Page 24
20
DLR3110 Rack Mount Digital Pressure Calibrator Manual
Figure 5-6. Overwriting Span Calibration Points
To overwrite a span calibration point or hysteresis, step to the desired point using the
DOWN
arrow key and then
modify and enter the new value as described in Section 5.6.1 on page 17.
Figure 5-7. Configuration Set-Up Mode
0
LOAD
mV/V OUTPUT
SPAN 4
SPAN 3
SPAN 1
SPAN 2 (ORIGINAL POINT)
CONFIG ?
ZERO
DISPLAY
TARE
YES
NO
CE
ENTER
