24 DLR3110 Rack Mount Digital Pressure Calibrator Manual
5.13.1 Port 1 Set-Up Menu
Table 5-11 outlines the parameters of the Port 1 Set-up menu.
LED Display Alpha-Numeric Display Key Pressed Remarks
SET-UP I/O YES key Enters I/O menu
NO key Continue to PORT 1 ?
SET-UP PORT 1 ? YES key See Section 5.13.1
NO key Continue to PORT 2 ?
SET-UP PORT 2 ? YES key See Section 5.13.6 on page 29
NO key Continue to TIME&D ?
SET-UP TIME&D ? YES key See Table 5-18 on page 29
NO key Continue to PARAL ?
SET-UP PARAL ? YES key Requires the installation of the parallel
output option board
NO key Continue to ANALOG ?
SET-UP ANALOG ? YES key Requires the installation of the analog
output option board
NO key Continue to INPUT ?
SET-UP INPUT ? YES key See Section 5.13.8 on page 30
NO key Continue to TRIP PT ?
SET-UP TRIP PT? YES key Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF or ON
NO key Continue to EXIT
---- EXIT ? YES key Return to Section 5.4 on page 13
NO key Return to PORT 1 ?
Table 5-10. I/O Set-Up Mode Parameters
LED Display Alpha-Numeric Display Key Pressed Remarks
SET-UP PORT 1 ? YES key Enters Port 1 Set-up
PORT 1 OFF Press YES key to
to accept, NO
key to exit
Press LEFT or RIGHT arrow keys to
change the current state of the selection.
OFF, PRINTER, DUPLEX, SIMPLEX
PORT 1 PRINTER See Table 5-12 on page 25
PORT 1 DUPLEX See Table 5-14 on page 26
PORT 1 SIMPLEX See Table 5-17 on page 28
---- EXIT ? YES key Return to Table 5-10 on page 24
NO key Return to PORT 1?
Table 5-11. Port 1 Set-Up Menu
