Configuration and Calibration 21
5.11 Configuration Set-Up Mode Selection
To access Configuration mode, see Section 5.4 on page 13. Press UP and DOWN arrow keys to step through and
select parameters. Press LEFT or RIGHT arrow keys to change the current configuration of the selected parameter.
The Configuration mode may be exited at anytime by pressing the CE key. If the CE key is pressed the prompt
Exit? YES or NO scrolls continuously until the YES or NO key is pressed. See Figure 5-7 on page 20 fo r an
example of the DLR3110’s display.
* Represent existing data.
** Requires activation by an input. See Section 5.13 on page 23.
LED Display Alpha-Numeric Display Key Pressed Remarks
SET-UP CONFIG ? YES key Will enter CONFIG menu
XXX* FILTER 5 UP or DOWN
arrow
Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. 1 to 10 by 1; 10 to 20
by 2; 20 to 50 by 5.
AUTO DISP/SEC UP or DOWN
arrow
Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. AUTO, 2, 3 or 5
OFF ZERO % Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF, 0.5, 1, 2, 5 or
100
Full ZERO +/- % Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. Full, 0.05, 0.1, 0.2,
0.5, 1 or 1.5
OFF AZM +/- Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF, 0.5, 1, 3, 5 or 10
OFF MOTION Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF, 1, 3, 5, 10, 20 or
50
OFF ZERO SET Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF, Auto.tr or
OFFSET
OFF MIN Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF or ON
OFF MAX Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. OFF or ON
OFF FREEZE **Press LEFT or RIGHT arrow keys to
change the current configuration of the
selected parameter. 1 sec to 10 sec by 1
SET-UP EXIT ? YES key Return to MAIN menu SET-UP/CONFIG.
See Section 5.4 on page 13.
NO key Return to XXX/FILTER 5 ?
Table 5-9. Configuration Mode Parameters
