62 DLR3110 Rack Mount Digital Pressure Calibrator Manual
8.0 Model Numbering System
DLR3110 - ____ ____ ____ ____ ____
≠ ≠ ≠ ≠ ≠
+-----------------------------+ ≠ ≠ ≠ ≠
≠ MOUNTING ≠ ≠ ≠ ≠
≠ ≠ ≠ ≠ ≠
A - 19 in. Rack Mount
≠ ≠ ≠ ≠
≠ ≠ ≠ ≠
+-------------------------------------+ ≠ ≠ ≠
≠ POWER REQUIREMENTS ≠ ≠ ≠
≠ ≠ ≠
A - 120 VAC Operation
≠ ≠ ≠
D - 220 VAC Operation
≠ ≠ ≠
≠ ≠ ≠
+----------------------------------------------+ ≠ ≠
≠ PRESSURE RANGE ≠ ≠
≠ ≠ ≠
A - 0-3 PSIG K - 0-2500 PSIG N - 0-15 PSIA
≠ ≠
B - 0-10 PSIG L - 0-5000 PSIG P - 0-25 PSIA
≠ ≠
C - 0-15 PSIG M - 0-10000 PSIG R - 0-50 PSIA
≠ ≠
D - 0-25 PSIG S - 0-100 PSIA
≠ ≠
E - 0-50 PSIG T - 0-250 PSIA ≠ ≠
F - 0-100 PSIG V - 0-500 PSIA
≠ ≠
G - 0-250 PSIG W - 0-1000 PSIA
≠ ≠
H - 0-500 PSIG Y - 0-2500 PSIA
≠ ≠
J - 0-1000 PSIG Z - 0-10000 PSIA
≠ ≠
≠ ≠
+------------------------------------------------------+ ≠
≠ ACCURACY ≠
≠ ≠
A - 0.05% Indicated value from 20% of full scale
≠
B - 0.1% Indicated value from 20% of full scale
≠
C - 0.25% Indicated value from 20% of full scale ≠
≠
+---------------------------------------------------------------+
≠ OPTIONS
≠
A – Standard unit which includes, multiple conversion units, min/max,
freeze mode, RS232, RS422 and RS485
B – Standard unit plus two Relays and Setpoints option
C - Standard unit plus selectable scalable analog output
0-5VDC, 1-6VDC, 0-10VDC, 0-20mA, and 4-20mA
D - Standard unit plus parallel BCD output
NOTE: DLR3110 is available with test port on back of chassis.
