Refer to the Brocade Network Advisor User Manual for detailed instructions on how to add, edit, view,
and remove thresholds.

Port health and CRC monitoring

There are two types of CRC errors that can be logged on a switch; taken together they can assist in
determining which link introduced the error into the fabric. The two types are plain CRCs, which have
bad end-of-frame (EOF) markers and CRCs with good EOF (crc g_eof) markers. When a crc g_eof
error is detected on a port, it indicates that the transmitter or path from the sending side may be a
possible source. When a complete frame containing a CRC error is first detected, the error is logged,
and the good EOF (EOFn) is replaced with a bad EOF marker (EOFni). Because Brocade switches
forward all packets to their endpoints, changing the EOF marker allows the packet to continue but not
be counted.

For thresholding and fencing purposes, only frames with CRC errors and good end-of-frame markers
are counted. This enables you to know exactly how many errors were originated in a specific link.

Recommended port configuration settings

The following table lists the recommended settings for physical port, E_Port, FOP_Port, and FCU_Port
for both the host device and the storage device.

Recommended configuration for the port class

TABLE 22

E=Error_Log, S=SNMP_Trap,
P=Port_LOG_LOCK,
M=EMAIL_ALERT, F=Port Fence

Trait Configuration

Class

Area

Default Custom Unit

Time
Base

Low
Thresh

High
Thresh

Buffer

Default Custom Below

Above

Port

Link Loss

X

Errors

Minute 0

500

50

X

Sync Loss

X

Errors

Minute 0

500

50

X

Signal Loss

X

Errors

Minute 0

5

0

X

Protocol Error

X

Errors

Minute 0

5

0

X

Invalid Words

X

Errors

Minute 0

25

0

X

E

Invalid CRCs

X

Errors

Minute 0

5

0

X

E

RX
Performance

X

Percentage Minute 0

100

0

X

TX
Performance

X

Percentage Minute 0

100

0

X
