SFP class default settings (Continued)

TABLE 8

Area

Description

Default threshold settings Default alarm

settings

Threshold state

Receive power
(RXP)

Monitors receive
power

Unit: µWatts

Time Base: none

Low: 0

High: 5000

Buffer: 25

Below: 1

Above: 1

Out_of_range

Out_of_range

Transmit power
(TXP)

Monitors transmit
power

Unit: µW

Time Base: none

Low: 0

High: 5000

Buffer: 25

Below: 1

Above: 1

Out_of_range

Out_of_range

Current

Monitors SFP current

Unit: mAmps

Time Base: none

Low: 0

High: 50

Buffer: 1

Below: 1

Above: 1

Out_of_range

Out_of_range

Voltage

Monitors SFP electrical
force

Unit: mVolts

Time Base: none

Low: 2970

High: 3630

Buffer: 10

Below: 1

Above: 1

Out_of_range

Out_of_range

Power on hours

Monitors the number of
hours the SFP is
powered on.

Unit: Changes

Time Base: none

Low: 0

High: 0

Buffer: 0

Below: 0

Above: 0

Informative

Informative

Performance monitoring guidelines and default settings

Performance monitoring serves as a tuning tool. The Performance Monitor class groups areas that
track the source and destination of traffic. Use the Performance Monitor class thresholds and alarms
to determine traffic load and flow and to reallocate resources appropriately.

NOTE
Performance Monitoring is not supported on VE_Ports.
