Physical port setting guidelines
It is recommended that you use the default settings listed in
on page 67 for
most Port class areas. Consider the Port class to be a superset containing the E_Port, FOP_Port, and
FCU_Port subclasses. If you make a change to a default setting for an area in the Port class, it applies
to all of the subclasses. This is convenient if you have determined that changes you plan to make to the
default settings for the subclasses are the same for certain areas. In this case, you only need to make
the changes to the Port class. Note, however, that if you make a change to one of the subclasses, that
change overrides the Port class setting.
Port class default settings
Port class default settings
TABLE 16
Area
Description
Default threshold
settings
Default alarm
settings
Threshold
state
Cyclic
redundancy
check (CRC
with good
EOF (crc
g_eof)
markers)
Monitors the number of CRC errors. Unit: Errors
Time Base: minute
Low: 0
High: 1000
Buffer: 100
Below: 0
Above: 0
Informative
Out_of_range
Invalid
transmission
words (ITW)
Monitors the number of invalid
words transmitted.
Unit: Errors
Time Base: minute
Low: 0
High: 1000
Buffer: 100
Below: 0
Above: 0
Informative
Out_of_range
Class 3
discards
(C3TX_T0)
Class 3 discards frames due to
time-out or destination unreachable.
Unit: Errors
Time Base: minute
Low: 0
High: 2
Buffer: 0
Below: 0
Above: 0
Informative
Out_of_range
Link loss
Monitors the number of link failures. Unit: Errors
Time Base: minute
Low: 0
High: 500
Buffer: 50
Below: 0
Above: 0
Informative
Out_of_range
Signal loss
Monitors the number of signal loss
errors.
Unit: Errors
Time Base: minute
Low: 0
High: 5
Buffer: 0
Below: 0
Above: 0
Informative
Out_of_range
