Specifying the 16 Gbps SFP type
You can use the --sfpType operand as part of the thconfig command to manage the actions and
thresholds for the Current, Voltage, RXP, TXP, and Temperature areas of the 16 Gbps SFPs as
shown in the following example.
switch:admin> thconfig --apply sfp --sfptype sfptype1 -area TXP 1270 temperature 82
current 10
If you do not provide the SFP type parameters (as shown in the example below) the existing
thresholds and actions of the SFP class are changed to their default values.
switch:admin> thconfig --set sfp -area TXP --sfptype
SFP types for the 10 Gbps SFPs and 16 Gbps SFPs and QSFPs are listed in the table below.
16 Gbps and QSFP configurable SFP types
TABLE 13
SFP Type
Serial
Number
Area
Default High
Default Low
16GSWL
HA
Temperature (°Centigrade)
85
-5
Voltage (mVolts)
3600
3000
RXP (μWatts)
1259
32
TXP (μW)
1259
126
Current (mAmp)
12
3
Power on Hours (hours)
0
0
16GLWL
HB
Temperature (°C)
90
-5
Voltage (mV)
3600
3000
RXP (μW)
1995
10
TXP (μW)
1995
126
Current (mA)
70
1
QSFP
HT
Temperature (°C)
85
-5
Voltage (mV)
3600
2970
RXP (μW)
2180
44
TXP (μW)
0
0
Current (mA)
10
1
10GSWL
KA
Temperature (°C)
90
-5
Voltage (mV)
3600
3000
RXP (μW)
1999
30
Specifying the 16 Gbps SFP type
60
Fabric Watch Administrators Guide
53-1003142-01
