FOP_Port and FCU_Port subclass default settings (Continued)

TABLE 18

Area

Description

Default threshold
settings

Default alarm
settings

Threshold state

Link reset

Monitors the number of link
resets sent by a given port
(LR-Out) and received on a
given port (LR-In).

Unit: Errors

Time Base: minute

Low: 0

High: 500

Buffer: 50

Below: 0

Above: 0

Informative

Out_of_range

VE_Port class default settings

NOTE
Only a subset of areas can be configured for the VE_Port class. When setting VE_Port thresholds for
the Packet Loss area, the threshold value accepts up to two decimal points; for example: -value 0.60,
as shown in

Packet loss monitoring enhancements on the VE_Port

on page 78.

VE_Port class default settings

TABLE 19

Area

Description

Default threshold settings Default alarm

settings

Threshold state

Packet loss

The number of packets
routed through a port
exceeds the port
bandwidth.

Unit: Errors

Time Base: minute

Low: 0

High: 10

Buffer: 0

Below: 0

Above: 0

Informative

Out_of_range

State changes
(ST)

Monitors state changes.

Unit: Changes

Time Base: minute

Low: 0

High: 50

Buffer: 0

Below: 0

Above: 0

Informative

Out_of_range

Utilization

The percent of utilization
for the port at the time of
the last poll.

Unit: Errors

Time Base: minute

Low: 0

High: 100

Buffer: 0

Below: 0

Above: 0

Informative

Out_of_range

Packet loss monitoring enhancements on the VE_Port

Fabric Watch provides monitoring for packet loss percentage for the VE_Port. Previously, configuring
the packet loss percentage for the VE_Port was allowed as a whole number; however, packet loss is

VE_Port class default settings
