E_Port class default settings (Continued) TABLE 17
Area Description Default threshold settings Default alarm
settings
Threshold state
Received packets
(RXP) Monitors the receive rate,
by percentage. Unit: Percentage (%)
Time Base: minute
Low: 0
High: 100
Buffer: 0
Below: 0
Above: 0
Informative
Informative
State changes
(ST) Monitors state changes. Unit: Changes
Time Base: minute
Low: 0 High: 50 Buffer: 0
Below: 0
Above: 0
Informative
Out_of_range
Transmitted
packets (TXP) Monitors the transmit rate,
by percentage. Unit: Percentage (%)
Time Base: minute
Low: 0
High: 100
Buffer: 0
Below: 0
Above: 0
Informative
Informative
Trunk utilization The percent of utilization
for the trunk at the time of
the last poll. Unit: Percentage (%)
Time Base: minute
Low: 0
High: 100
Buffer: 0
Below: 0
Above: 0
Informative
Informative
Link reset Monitors the number of link
resets sent by a given port
(LR-Out) and received on a
given port (LR-In). Unit: Errors
Time Base: minute
Low: 0
High: 500
Buffer: 50
Below: 0
Above: 0
Informative
Out_of_range
NOTE
Port fencing can be enabled on 7500/FR18i VE ports under the E_Port class. Port fencing is not
supported on FX8-24/7800 VE ports, but is supported on FR4-18i/7500 VE ports.
FOP_Port and FCU_Port subclass setting guidelines
FOP_Port and FCU_Port guidelines for the areas listed below represent a more aggressive approach
in most areas.
NOTE
The settings in these subclasses include settings for the host bus adapter (HBA) ports as well as the
storage ports.
FOP_Port and FCU_Port subclass setting guidelines
