2-32
IM 04P01B01-61E
Personalize
Click here (or choose [Setting] > [SET [Basic] Setting] > [Add Function]/[Time Print Format])
Add Function
• Bias
Select Use to enable the setting of a bias for the measurement channels. Bias and
Calibration cannot be enabled simultaneously.
• SQRT Low-cut
Enables/Disables the square root low-cut function.
Select
Use to enable the setting of the low-cut function when measurement channels
are set to square root computation.
• 1-5V Low-cut
Enables/Disables the 1-5V low-cut function.
Select
Use to enable the setting of the low-cut function when measurement channels
are set to 1-5V signals.
• Alarm Delay
Enables/Disables the alarm delay function.
Select
Use to enable the selection of the delay high/low limit alarm for the alarm type.
• Calibration (/CC1 Option)*
* For recorders with firmware version 1.21 or later
Enables/Disables the calibration correction.
Select
Use to enable the calibration correction function. Bias and Calibration cannot
be enabled simultaneously.
Time Print Format
• Alarm Print, Message Print, Record On Print, and Chart Speed Change
Print
Sets the time printout format for each type of printout. The format of year, month, and
day varies depending on the Date Format setting on next page.
Selections Format (example) Selections Format (example)
HH:MM 10:00 M/D H:M:S Nov.09 10:00:00
HH:MM:SS 10:00:00 YMD H:M:S Nov.09.2005 10:00:00
M/D H:M Nov.09 10:00 NONE Does not print the date/time.*
* Selectable for Message Print only.
2.7 Setting the Items in Basic Setting Mode
