2-19
IM 04P01B01-61E
Configuring the Recorderr
1
2
3
4
Index
Message Format (/BT1 Option)*
* Function available on recorders with firmware version 1.31 or later.
Set the message format.
Click a text box from 1 to 5. A dialog box used to set the message format opens. Set the
format using the selectable items displayed in the dialog box and space.
Number of characters per message: Up to 35 (µR10000) and up to 69 (µR20000).
H:M 5 H:M:S 8
M/D H:M 11 M/D H:M:S 14
D/M H:M 11 D/M H:M:S 14
D.M H:M 11 D.M H:M:S 14
M.D H:M 12 M.D H:M:S 15
Y/M/D H:M:S 19 M/D/Y H:M:S 19
D/M/Y H:M:S 19 D.M.Y H:M:S 19
M.D.Y H:M:S 20
H, M, and S are hour, minute, and second, respectively, for H:M and H:M:S.
M, D, and Y are month, day, and year, respectively for M/D, D/M, D.M , M.D,
Y/M/D, M/D/Y, D/M/Y, D.M.Y, and M.D.Y.
Format symbols and number of characters used
Num. of
Chars
Symbol Num. of
Chars
Symbol Num. of
Chars
Symbol
01 to 24 7
L01 to L16 1 to 16
0A to 1P 9
Setup Example
10 th and 11 th characters of the message
string (9 characters already used, so this
represents the next characters.)
Message 1 string of the standard function: Process-1°C
Message 1 printout result: 06/30 10:10 Process-1 134.8°C
Message format 1: M/D H:M L09 01L02
Message value on CH1 (no unit)
Space (number of characters: 1)
Space
1-9
th characters of the message string
Date/Time
2.6 Setting the Items in Setting Mode and the Data Display Method
