Channel
Click here (or choose [Setting] > [SET [Basic] Setting] > [Burnout]/[RJC])
Click twice to unselect the channel.
Drag the pointer while holding down the right mouse button to select multiple lines.
Copies/Pastes the
settings of a channel to
other channels.
Burnout
Up:
Records off the scale on the 100% side when a thermocouple burnout is
detected.
Down: Records off the scale on the 0% side when a thermocouple burnout is detected.
OFF: Disable the burnout detection function.
RJC
• Type
Internal: Uses the RJC function of the recorder.
External: Uses an external RJC function.
• Volt (uV)
Sets the compensation voltage when using an external RJC function. The
compensation voltage can be set in the range of –20000 µV to 20000 µV.
2.7 Setting the Items in Basic Setting Mode
