2-25
IM 04P01B01-61E
Configuring the Recorderr
1
2
3
4
Index
Measure Alarm Hysteresis
Sets the alarm hysteresis of measurement channels in the range of 0.0% (OFF) to 1.0%
of the recording span in 0.1 steps. The hysteresis applies to all high limit and low limit
alarms of measurement channels.
Math Alarm Hysteresis (Models with the Computation Function (/M1
Option))
Sets the alarm hysteresis of computation channels in the range of 0.0% (OFF) to 1.0%
of the recording span in 0.1 steps. The hysteresis applies to all high limit and low limit
alarms of computation channels.
Remote (Models with Remote Control Input (/R1 Option))
Remote 1 to Remote 5 corresponds to remote control input terminals 1 to 5. The
following functions can be assigned.
Display Description
NONE No function is assigned.
Record On/Off Starts/stops recording.
Chart speed Changes the chart speed.
Time adjust Adjusts the internal clock to the nearest hour.
MATH start/stop Starts/stops the computation on the computation function
(/M1 option).
MATH reset Resets the computed result of the computation function
(/M1 option).
Manual print Executes manual printout.
Alarm ACK Executes alarm output release.
message # Prints message # (where # is a value between 1 and 5).
Priority to Remote Recording* Starts/stops recording.
Switching Batch Comment* Switches between start printout and start printout 2. Or,
switches between end printout and end printout 2.
* Selectable on recorders with firmware version 1.31 or later and header printout (/BT1 option).
2.7 Setting the Items in Basic Setting Mode
