Wa t l o w S e r i e s 9 7 P a r a m e t e r s ■ 6 . 2 1
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
Active if Output 4 is process (97 _
_-_ _ _ M-_ _ _ _) and
Calibration Lock (Lockout
Menu) is not set to [hide]
1622 w 10.00 0.00 to 99.99 [4`10] Output
Calibration 4, 10V
Enter the output
value in volts as
measured.
Active if Output 4 is process (97 _
_-_ _ _ M-_ _ _ _) and
Calibration Lock (Lockout
Menu) is not set to [hide]
1621 w 1.00 0.00 to 99.99 [4``1] Output
Calibration 4, 1V
Enter the output
value in volts as
measured.
Active if Output 4 is process (97 _
_-_ _ _ M-_ _ _ _) and
Calibration Lock (Lockout
Menu) is not set to [hide]
1620 w 20.00 0.00 to 99.99 [4`20] Output
Calibration 4,
20mA
Enter the output
value in milliamps
as measured.
Active if Output 4 is process (97 _
_-_ _ _ M-_ _ _ _) and
Calibration Lock (Lockout
Menu) is not set to [hide]
1619 w 4.00 0.00 to 99.99 [4``4] Output
Calibration 4,
4mA
Enter the output
value in milliamps
as measured.
[cout] Output Calibration
Menu
[Fcty] Factory Page
Factor
y Page / Process Output Calibration Menu
