Active if Upper Display [UdSP] is
set to [USEr].
1401 r/w
1402 r/w
1403 r/w
1404 r/w
characters
1 to 4
[____] 0: _
1: A
2: b
3: C
4: c
5: d
6: E
7: e
8: F
9: g
10: H
11: h
12: I
13: i
14: J
15: L
16: l
17: M (1st half)
18: M (2nd half)
19: N
20: n
21: O
22: o
23: P
24: r
25: S
26:t
27: U
28: u
29: W (1st half)
30: W (2nd half)
31: backwards “C”
32: backwards “c”
33: y
34: 0
35: 1
36: 2
37: 3
38: 4
39: 5
40: 6
41: 7
42: 8
43: 9
44: blank
45: -
46: .
47:-1
48: li
49: il
50: ll
51: i
52: l
53: l
54: ° [UP`L] Upper Display
User Limit
Message
Select four
characters for limit
message.
Wa t l o w S e r i e s 9 7 P a r a m e t e r s ■ 6 . 1 5
Setup Page / Display Menu
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
