4 . 4 ■ N a v i g a t i o n Wa t l o w S e r i e s 9 7
Navigation
Software Map
Figure 4.4 — Software Map.
[LIM]
Limit Menu
[OPEr]
Operations Page
[OPEr] Operations Page
[L`Lo] Low Limit Set Point
[L`hi] High Limit Set Point
[CAL1] Calibration Offset
[OPEr] Operations Page
[Pr1`] Process 1
[L`St] Limit Status
[AL`2] Alarm 2 Status
[AL`3] Alarm 3 Status
[AL`4] Alarm 4 Status
[E`St] Event Input Status
[OPEr] Operations Page
[A2Lo] Alarm 2 Low
[A2hi] Alarm 2 High
[A3Lo] Alarm 3 Low
[A3hi] Alarm 3 High
[A4Lo] Alarm 4 Low
[A4hi] Alarm 4 High
‰
‰
‰
¿
¿
[Mon]
Monitor Menu
[OPEr]
[ALM]
Alarm Menu
[OPEr]
¯
¯
[``97]
Process Value
[safe]
Home Page
Limit Status
[``97]
Process Value
[Safe] Limit Status
[LIM]
Limit Menu
[OPEr] Operations Page
[InP1]
Input 1 Menu
[`SEt] Setup Page
[`LOC]
Custom Menu
[FctY] Factory Page
Home Page
¿ and ¯
for 3 seconds
Operations Page
Setup Page
Factory Page
¿ and ¯
for 3 seconds
‰ and RESET
for 6 seconds
¿ to cycle through menus
‰ to select a parameter in a menu
¿ to select a value
‰ to enter a value and go to the next parameter
RESET anytime to return to the Home Page
