Active: Always 1515 r none [line] Line Frequency
Displays the AC line
frequency in Hz.
none [``no] (0)
[coM] sends Modbus
packet every one
second (2)
[tSht] Communication
Test and
Troubleshooting
Helps solve
problems with the
controller.
Active: Always 1505 r none [cnt2] Channel 2 A-D
Counts
Displays the raw
channel 2 A-D
counts.
Active: Always 1504 r none [cnt1] Channel 1 A-D
Counts
Displays the raw
channel 1 A-D
counts.
Active: Always 1501 r none [Acnt] Ambient A-D
Counts
Displays the raw
ambient channel A-
D counts.
Active: Always 1500 r none [amb] Ambient
Temperature
Reads the ambient
temperature in 0.1
degrees Fahrenheit.
Active: Always 1707 r none 0.0 to 99.9 [hres] High Resolution
Displays high
resolution input
value.
Active: Always 1513 r/w [`OFF] [`OFF] turn off cyclical
display test (0)
[``on] turn on the
cyclic display test (1)
[DISP] Test Display
Tests the indicator
lights on the front
panel.
Active: Always 1514 r/w [none] [none] none (0)
[Out1] Output 1 (1)
[Out2] Output 2 (2)
[Out3] Output 3 (3)
[Out4] Output 4 (4)
[all`] all outputs (5) [tout] Test Output
Turns on specific
output.
Wa t l o w S e r i e s 9 7 P a r a m e t e r s ■ 6 . 1 9
Factor
y Page / Diagnostics Menu
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
