Active if Output 4 is equipped for
communications (97 _ _-_ _ _ R-
_ _ _ _ or 97 _ _-_ _ _ U-_ _ _ _)
and Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [9600] [1200] 1200
[2400] 2400
[4800] 4800
[9600] 9600
[1(20] 19.2K [bAUd] Baud Rate
Sets
communications
baud rate.
Active if Output 4 is retransmit
(97 _ _-_ _ _ M-_ _ _ _), and
Analog Output 4 (Output 4
Menu) is set to [`yes] and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* 0 -1999 to 9999 [ACAL] Analog Output
Offset
Sets analog output
offset.
Active if Output 4 is equipped for
retransmit (97 _ _-_ _ _ M-_ _ _ _),
and Analog Output 4 (Output 4
Menu) is set to [`yes] and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* 999 Analog Range Low to
9999
[A`hi] Analog Output
High
Sets analog output
range high scaling.
Active if Output 4 is equipped for
retransmit (97 _ _-_ _ _ M-_ _ _ _),
and Analog Output 4 (Output 4
Menu) is set to [Proc] and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* -999 -1999 to Analog Range
High
[A`Lo] Analog Output
Low
Sets analog output
range low scaling.
Active if Output 4 is equipped for
retransmit (97 _ _-_ _ _ M-_ _ _ _)
and Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [4-20] [4-20] 4-20 mA
[0-20] 0-20 mA
[0-`5] 0-5VÎ (dc)
[1-`5] 1-5VÎ (dc)
[0-10] 0-10VÎ (dc) [Prc4] Process 4 Type
Sets process 4 out-
put type.
Active if Output 4 is equipped for
retransmit (97 _ _-_ _ _ M-_ _ _ _)
and Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [proc] [``no] not active
[proc] process [Aout] Analog Output 4
Selects output 4
retransmit signal.
Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D-_ _ _ _),
Output 4 is Set to [``AL]
(Alarm) and Setup Page Lock
(Lockout Menu) is not set to
[hide].
none* [`yes] [``no] no
[`Yes] yes [Anu4] Alarm
Annunciation 4
Selects alarm 4
annunciation option.
Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D-_ _ _ _),
Output 4 (Output 4 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [al`0] [al`0] alarm condition
de-energizes output
[al`C] alarm condition
energizes output
[Lgc4] Alarm Logic 4
Selects alarm 4
output condition in
alarm state.
Wa t l o w S e r i e s 9 7 P a r a m e t e r s ■ 6 . 1 3
Setup Page / Output 4 Menu
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
NOTE: For more information about how parameter seetings affect the controller’s operation, see Chapter Five, Features.
*Output 4 parameters cannot
be changed with the Modbus
interface.
