NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
Active if Setup Page Lock
(Lockout Menu) is not set to
[hide].
607 r/w [nLat] [`Lat] latching (0)
[nLat] no latching (1) [`Err] Input Error
Latching
Selects input error
latching mode.
Active if Setup Page Lock
(Lockout Menu) is not set to
[hide].
901 r/w [``°F] [``°C] Celsius (1)
[``°F] Fahrenheit (0) [`C-F] C or F
Selects the
temperature scale
for the input.
Converts all
temperature
parameters.
[glbl] Global Menu
[`set] Setup Page
Active if Lower Display [LdSP] is
set to [USEr].
1410 r/w
1411 r/w
1412 r/w
1413 r/w
characters
1 to 4
[____] see Upper Display User
Limit Message
[Lo`L] Lower Display
User Limit
Message
Selects four
characters for the
user message to
appear while the
unit is in a limit
condition.
Active if Lower Display [LdSP] is
set to [USEr].
1406 r/w
1407 r/w
1408 r/w
1409 r/w
characters
1 to 4
[____] see Upper Display User
Limit Message
[Lo`S] Lower Display
User Safe Message
Selects four
characters for user
message to appear
while the unit is in a
safe condition.
Active: Always. 1405 r/w [L`St] [L`St] limit status
(0):[SAFE]; [``hi];
[``lo]
[USEr] user message
(1)
[L`hi] high limit set
point (3)
[L`Lo] low limit set
point (2)
[LdSP] Lower Display
Selects the value or
message that will
appear in the lower
display.
Limit Status or User
Limit Message, if
selected, will flash in
the lower display if
out of limit range.
6 . 1 6 ■ P a r a m e t e r s Wa t l o w S e r i e s 9 7
Setup Page / Global Menu
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
