NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (7)

[r380] RTD Calibration,

380

Stores 380.00

calibration for input
1 RTD.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (6)

[r`15] RTD Calibration,

15

Stores 15.00

calibration for input
1 RTD.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (5)

[Lead] Lead Resistance

Calibration

Stores calibration
for lead resistance.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (4)

[`gnd] Set Ground

Stores calibration for
ground at gains of 1
and 32.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (3)

[tc32] Thermocouple

Calibration, 32º

Stores 32 degrees F
type J calibration.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (1)

[tc00] Thermocouple

Calibration, 0mV

Stores 0.000mV
calibration for input
1 thermocouple.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1603 w

[``no]

[``no] no (0)
[`yes] yes (2)

[tc50] Thermocouple

Calibration, 50mV

Stores 50.000mV
calibration for input
1 thermocouple.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1602 w

[``no]

[``no]

no (0)

[`yes] yes (800)

[dflt] Default Settings

Restores default
settings.

Active if Calibration Lock

(Lockout Menu) is not set to
[hide]

1601 w

[``no]

[``no] No (0)
[`yes] Yes (1)

[`rSt] Restore Factory

Calibration
Restores factory
calibration (Stores
factory calibration
with special key
sequence).

[cin1]

Input Calibration
Menu

[Fcty] Factory Page

6 . 2 0

P a r a m e t e r s

Wa t l o w S e r i e s 9 7

Factor

y Page / Calibration 1 Menu

Display

Parameter

Range

Default

Modbus

Conditions for

Address

Parameters to Appear

read/write
