Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D-_ _ _ _),
Output 4 (Output 4 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [both] [both] both
[``hi] high
[``lo] low [Sid4] Alarm Active Sides
4
Selects alarm 4 side
option.
Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D -_ _ _ _),
Output 4 (Output 4 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [``no] [``no] no action
[`yes] silence 4
enabled
[SiL4] Silencing 4
Enables Silence 4.
Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D-_ _ _ _),
Output 4 (Output 4 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [``no] [``no] no action
[`Yes] latching
enabled
[Lat4] Latching 4
Enables alarm 4
latching.
Active if Output 4 is equipped for
a relay, (97 _ _-_ _ _ D -_ _ _ _ ,
Output 4 (Output 4 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
none* 3 1 to 9999 [hys4] Alarm Hysteresis 4
Sets the switching
hysteresis for the
alarm output. This
defines a band on
the inside of the
alarm set point.
When the process
temperature is in
this band, the alarm
state will not
change.
Active if Output 4 is equipped for
a relay (97 _ _-_ _ _ D-_ _ _ _)
and Setup Page Lock (Lockout
Menu) is not set to [hide].
none* [`OFF] [`OFF] off
[`AL`] alarm [Ot`4] Output 4
Selects output 4
type.
[Out4] Output 4 Menu
[`set] Setup Page
Active if Output 3 hardware is
present (97 _ _-_ _ D _-_ _ _ _),
Output 3 (Output 3 Menu) is
set to [``AL] (Alarm) and
Setup Page Lock (Lockout
Menu) is not set to [hide].
742 r/w [`Yes] [``no] no (0)
[`Yes] yes (1) [Anu3] Alarm
Annunciation 3
Selects alarm 3
annunciation option.
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
6 . 1 2 ■ P a r a m e t e r s Wa t l o w S e r i e s 9 7
Setup Page / Output 4 Menu
Display Parameter Range Default Modbus Conditions for
Address Parameters to Appear
read/write
*Output 4 parameters cannot
be changed with the Modbus
interface.
