Active if communications is

installed.

Active if

[glbl] is set to [`Off].

869 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[C|wd] Comms Watchdog

Alarm Config.

Selects the commu-
nications watchdog
alarm configuration.

Active if

[glbl] is set to [`Off].

868 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[``OU] Over Voltage

Alarm Config.

Selects the line over-
voltage alarm config-
uration.

Active if

[glbl] is set to [`Off].

867 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[``UC] Voltage Compensa-

tion Alarm Config.

Selects the line com-
pensation alarm con-
figuration.

Active if

[glbl] is set to [`Off].

866 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[Freq] Frequency Out of

Tolerance Alarm
Configuration

Select frequency tol-
erance alarm config-
uration.

Active if heater diagnostics is

installed.

Active if controller is 3 phase.

991 r/w

[`100] (100)

[```0] to [`100]

(0 to 100)

[Ldif] Load Balance

Percentage

Selects the mini-
mum percentage
difference between
loads current in
phases.

Active if heater diagnostics is

installed.

Active if

[glbl] is set to [`Off].

Active if controller is 3 phase.

865 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[Lbal] Load Balance

Alarm Config.

Selects the load
balance alarm
configuration.

Active if controller is 3 phase, 3-

leg configuration.

Active if

[glbl] is set to [`Off].

864 r/w

[`std]

active (0)

[`std] active (0)
[`LaT] latched (1)
[`SIl] silenced (2)
[LaSI] latched and

silenced (3)

[p|bAl] Phase Balance

Alarm Config.

Select phase balance
configuration.

P a r a m e t e r s , C h a p t e r 6

Wa t l o w P o w e r S e r i e s

6 . 1 1

NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Control
Methods and Features.

Display

Parameter

Range

Default

Modbus

Conditions for

(Modbus Value)

Address

Parameters to Appear

read/write
