Active if heater diagnostics is
installed.
Active unless controller is 3
phase, 2 leg configuration.
Active if [`Hbo] is set to [``On].
5116 r/w [1]
5216 r/w [2]
5316 r/w [3] 10.0% of load
current
[```0] to [`Cur] 0 to
Load Current Amps
[1 Amp increment;
maximum will be de-
termined by Load
Rating] (0 to Load
Current Amps)
[`HbC] Heater Bakeout
Over Current Trip
Sets the maximum
heater current dur-
ing heater bakeout.
Output will shut
down at this value.
Active if heater diagnostics is
installed.
Active unless controller is 3
phase, 2 leg configuration.
Active if [`Hbo] is set to [``On].
5111 r/w [1]
5211 r/w [2]
5311 r/w [3] 1440 minutes
(1440) [```0] to [9999] 0 to
9999 minutes [1
minute increments]
(0 to 9999)
[Min] Heater Bakeout
Select Time
Selects the heater
bakeout time in min-
utes for chosen zone.
Active if heater diagnostics is
installed.
Active unless controller is 3
phase, 2 leg configuration.
5110 r/w [1]
5210 r/w [2]
5310 r/w [3] [`OFF] off (0) [`OFF] off (0)
[``On] selected (1) [`Hbo] Heater Bakeout
Select (On/Off)
Select heater bake-
out option for chosen
zone.
[OPt1] OPt2] [OPt3] Setup Options Zones 1, 2, and 3 Menus
[`Set] [`Set] [`Set] Setup Page
This menu is used to set up the options for the chosen zone. This set of menus is available only if
Heater Diagnostics is installed.
Zone 1 is used if Input/Output Configuration is single phase, single zone, or three phase.
Zone 1 and Zone 2 are used if Input/Output configuration is single phase, two zones.
All zones are used if Input/Output Configuration is single phase, three zones.
Active if [algo] is set to [Ph2t]
and [type] is set to [3ld] or
[3lid].
5108 r/w [``)0] (0) [``)0] to [`5)0]
(0 to 500)
[rdLy] Reactance Delay
for Transformer
Loads
Prevents half cycle
errors and restarts
on inductive loads.
Increase value until
half cycle errors no
longer appear.
Active unless Input/Output con-
figuration is 3 phase, 2-leg.
Active if [algo] is set to [Ph2t].
5105 r/w [1]
5205 r/w [2]
5305 r/w [3] [``$0] (40) [``)0] to [12)0] 0.0
to 120 seconds (.1
second increments)
(0 to 1200)
[Soft] Soft Start Time
(Sec)
Selects the time in
seconds for the
power level of the
chosen zone to
change from 0% to
100% when the
power cycles.
Active unless Input/Output con-
figuration is 3 phase, 2-leg.
Active if [algo] is set to [Ph2t].
5104 r/w [1]
5204 r/w [2]
5304 r/w [3] [`1)0] (100) [``)1] to [10)0] 0.0
to 100.0% [.1% incre-
ments]
(1 to 1000)
[rATE] Maximum Rate of
Change
(%/100msec)
Set maximum rate of
power change of the
power level for
selected zone when
input signal changes.
Display Parameter Range Default Modbus Conditions for
(Modbus Value) Address Parameters to Appear
read/write
6 . 8 ■ Wa t l o w P o w e r S e r i e s P a r a m e t e r s , C h a p t e r 6
