Watlow Power Series Rev H - Manual (Page 36)

6 . 4 ■ Wa t l o w P o w e r S e r i e s P a r a m e t e r s , C h a p t e r 6
Active with multiphase
configuration and heater diag-
nostics option is installed.
156 r n/a [```0] to [9999]
[kVA]
(0 to 9999)
[`HUA] Load Power (kVA)
Read calculated
(est.) load power.
NOTE: In 3 phase, 2-leg systems, [Cur2] is the current displayed; it is the average of phase 1 and phase 3 ( [Cur1] and
[Cur3] ).
Active with multiphase
configuration and heater diag-
nostics option is installed.
154 r [1]
164 r [2]
174 r [3] n/a [``00] to [9999] [A]
(0 to 9999)
[Cur1], [Cur2], [Cur3]
Load Current
(Amps) rms
Read measured load
current.
Active with multiphase
configuration.
152 r [1]
162 r [2]
172 r [3] n/a [``00] to [9999] [V]
(0 to 9999)
[Uol1], [Uol2], [Uol3]
Line Potential
(Volts) rms
Read measured line
voltage.
Active with multiphase
configuration.
n/a [```1] to [```3] [```1] , [```2] , [```3]
[Phas] Display Phase
Selection 1 to 3
Select phase for
display.
Active: Always.
Appears in Display Loop. 159 r [``)0] [``)0] to [10)0] [%]
(0 to 1000) [`Out] Output Power (%)
Displays present out-
put power.
Active: Always.
Appears in Display Loop. 151 r [V]
150 r [mA]
5102 r/w
[dig]
[``)0] [``)0] to [2)00] [mA]
(0 to 2000)
[``)0] to [1)00] [V]
(0 to 1000)
[``)0] to [10)0] [%]
(0 to 1000)
0.1 increments
[``In] Analog (mA or V)
or Numeric (%)
Input Signal
Displays mA/V
analog input; selects
numeric % power.
Multi-Phase
Active with multizone
configuration and heater diag-
nostics option is installed.
156 r [1]
166 r [2]
176 r [3] n/a [```0] to [9999]
[kVA]
(0 to 9999)
[HUa1], [HUa2], [HUa3]
Load Power (kVA)
Read calculated
(est.) load power.
Active with multizone
configuration and heater diag-
nostics option is installed.
154 r [1]
164 r [2]
174 r [3] n/a [``00] to [9999] [A]
(0 to 9999)
[Cur1], [Cur2], [Cur3]
Load Current
(Amps) rms
Read measured line
current.
Display Parameter Range Default Modbus Conditions for
(Modbus Value) Address Parameters to Appear
read/write
