Display Parameter Range Default Modbus Conditions for
(Modbus Value) Address Parameters to Appear
read/write
6 . 6 ■ Wa t l o w P o w e r S e r i e s P a r a m e t e r s , C h a p t e r 6
Active if [``In] is set to [Uolt]
voltage.
5013 r/w [1]
5023 r/w [2]
5033 r/w [3] [`)00] (0) [`)00] to
[Uol–] [- 2.5V]
(0 to Analog Input
High Voltage [-2.5V])
[Uol_] Analog Input Low
Voltage (Volts)
Sets voltage value
which will corre-
spond to 0% power if
input is voltage type.
Active if [``In] is set to [`nna]
current.
5012 r/w [1]
5022 r/w [2]
5032 r/w [3] [2)00]
(2000)
[nna_] [+ 5mA] to
[9(99]
(Analog Input Low
Current [+5mA] to
9999)
[nna–] Analog Input High
Current (mA)
Sets current value
which will corre-
spond to 100%
power if input is
current type.
Active if [``In] is set to [`nna]
current.
5011 r/w [1]
5021 r/w [2]
5031 r/w [3] [`)00] (0) [`)00] to [nna–]
[- 5mA]
(0 to Analog Input
High Current[-5mA])
[nna_] Analog Input Low
Current (mA)
Sets current value
which will corre-
spond to 0% power if
input is current type.
Active if input signal method is
set to [`dIG].
5103 r/w [1]
5203 r/w [2]
5303 r/w [3] [``)0] (0) [``)0] 0 percent to
[10)0] 100 percent
(0 to 1000)
[dFlt] Default Numeric
Input Signal (%)
Selects the power-on
level for chosen zone.
Active: Always.
[`dig] is not available if [Set`]
® [algo] in the Setup Page is
set to
[cont].
5101 r/w [1]
5201 r/w [2]
5301 r/w [3] [`nna] cur-
rent (1)
[`OFF] off (0)
[`nna] current (1)
[Uolt] voltage (2)
[`dig] keyboard or
comms (3)
[``In] Input Signal
Method Select
(dig, mA, Volt)
Select the input
signal method for
chosen zone.
[Ctr1] [Ctr2] [Ctr3] Setup Control Zone 1, 2, and 3 Menus
[`Set] [`Set] [`Set] Setup Page
This menu is used to set up the control for the chosen zone.
Zone 1 is used if Input/Output Configuration is single phase, single zone, or three phase.
Zone 1 and 2 are used if Input/Output Configuration is single phase, two zones.
All zones are used if Input/Output Configuration is single phase, three zones.
Active: Always. 80 r/w [``ON]] on
(0)
[``ON] on (0)
[`Off] off (1) [``UC] Line Voltage Com-
pensation
Automatically adjusts
output duty cycle to
compensate for line
voltage fluctuations.
