Setup Page
To enter the Setup Page, press the Home and Left keys ( ± ¬ ) together while in the Display Loop.
Each of the following menus in the Factory Page are selected by pressing the
Increment/Decrement keys (
У О ). Each press of the button will scroll you up or down
through these main menu options.
To select a parameter within a menu, use the Left/Right arrow keys ( ¬ ® ). The parameter
appears in the bottom display.
To select a value for each parameter (either alpha or numeric), use the Increment/Decrement
keys (
У О ). The value appears in the upper display.
Pressing the Home key ( ± ) in this menu will return you to the Display Loop.
The Setup Page contains ten menus:
Active if [algo] is set to [`ftb]. 56 r/w [1SEC] 1
second (0)
[1SEC] 1 second (0)
[4SEC] 4 second (1) [`FTB] Fixed Time Base
(Sec)
Set the fixed time
base in seconds for
selected zone.
Active: Always.
[cont] is not available if any
input on controller is digital.
[PH2t] phase angle is not
available with 3 phase, 2-leg
controllers.
NOTE: Changing this parameter will
restart the system.
55 r/w [`Off] non-
operational
(1)
[cont] dc contactor (0)
[`Off] non-operational
(1)
[`Ftb] fixed time base,
zero cross (2)
[Urtb] variable time
base, zero cross (3)
[PH2t] phase angle (4)
[ALgo] Power Control
Algorithm Select
Select power control
algorithm.
[algo] Setup Control Algorithm
[`Set] Setup Page
This menu is used to set the control algorithm for the system.
NOTE: Changing the algorithm will restart the system.
*NOTE: These menus are dependent on
the hardware options that are installed
in your controller. Please see the indi-
vidual menus for the options that must
be installed for each of these menus to
appear. [algo] [algo] Control
Algorithm
[Ctr1] Control Zone 1
[Opt1] *Options Zone 1
[Ctr2] Control Zone 2
[Opt2] *Options Zone 2
[Ctr3] Control Zone 3
[Opt3] *Options Zone 3
[`ALr] Alarms
Configuration
[COM] *Comms
Configurations
[rEtr] *Retransmit
Configuration
[`Set] Setup Page Select
Go to a setup menu.
Display Parameter Range Default Modbus Conditions for
(Modbus Value) Register Parameters to Appear
read/write
P a r a m e t e r s , C h a p t e r 6 Wa t l o w P o w e r S e r i e s ■ 6 . 5
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Control
Methods and Features.
