Watlow Power Series Rev H - Manual (Page 35)

Active with multizone
configuration.
152 r [1]
162 r [2]
172 r [3] n/a [```0] to [9999] [V]
(0 to 9999)
[Uol1], [Uol2], [Uol3]
Line Potential
(Volts) rms
Read measured line
voltage.
Active if heater diagnostics option
is installed and heater bakeout
is running in the zone.
157 r [1]
167 r [2]
177 r [3] n/a [9999] to [```0]
[minutes]
(9999 to 0)
[Hbt1], [Hbt2], [Hbt3]
Heater Bakeout
Timeout
Displays the time
left on a heater
bakeout cycle.
Active with multizone
configuration.
159 r [1]
169 r [2]
179 r [3] [``)0] [``)0] to [10)0] [%]
(0 to 1000)
[Out1], [Out2], [Out3]
Output Power (%)
Displays present out-
put power.
Active with multizone
configuration.
mA, r[1][2][3]
150,160,170
V, r[1][2][3]
151,161,171
dig, r/w
[1][2][3]
5102, 5202,
5302
[``)0] [``)0] to [2)00] [mA]
(0 to 2000)
[``)0] to [1)00] [V]
(0 to 1000)
[``)0] to [10)0] [%]
(0 to 1000)
0.1 increments
[In`1], [In`2], [In`3]
Analog (mA or V)
or Numeric (%)
Input Signal
Displays mA/V
analog input; selects
numeric % power.
Active with multizone
configuration.
n/a 1 [```1] to [```3] [```1] , [```2] [```3]
[2one] Display Zone
Selection
Select Zone 1, 2 or 3
for display.
Three Zone, Single Phase
Active with multizone
configuration and heater diag-
nostics option is installed.
156 r [1]
166 r [2] n/a [```0] to [9999]
(0 to 9999)
[HUa1], [HUa2]
Load Power (kVA)
Read calculated
(est.) load power.
Active with multizone
configuration and heater diag-
nostics option is installed.
154 r [1]
174 r [2] n/a [``00] to [9999]
(0 to 9999)
[Cur1], [Cur2]
Load Current
(Amps) rms
Read measured line
current.
Active with multizone
configuration.
152 r [1]
172 r [2] n/a [```0] to [9999]
(0 to 9999)
[Uol1], [Uol2]
Line Potential
(Volts) rms
Read measured line
voltage.
Display Parameter Range Default Modbus Conditions for
(Modbus Value) Address Parameters to Appear
read/write
P a r a m e t e r s , C h a p t e r 6 Wa t l o w P o w e r S e r i e s ■ 6 . 3
NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Control
Methods and Features.
NOTES:
What you see in each Page and in each Menu are factory set, depending on the options and settings in your controller.
Current operating parameters may be modified at any time with the use of a keypad or serial input.
The Input Signal Method Indicator will change depending on the Input Signal Method chosen — process, current, or volts.
