7 www.rosscontrols.com
• Remote Serial Bus system.
• Pneumatics and I/O are not in close
proximity with one another.
• M23, 12-Pin output extension to remote valve
island.
• I/O density per module = 8.
M23, 12-Pin
End Plate Kit
M23, 12-Pin
Cable
Series W66 18mm & 26mm
ISO 15407-2 Valves on one
island - no transition plate
needed.
I/O - Remote Configuration
