Ross Controls ROSS MODULAR I - Manual (Page 35)

35 www.rosscontrols.com
Serial Bus Product Compatibility
DeviceNet™
Adapter
RPSSCDM
ControlNet
Adapter
RPSSCCNA
EtherNet
Adapter
RPSSCENA
PROFIBUS
Adapter
RPSSCPBA
PLC-5™ with Network Port IOD NS NS NA
SLC 500™ with Network Port IOD NS NS NA
PLC-5 Processor via Network Module IOD NS NS 3
1756 Logix™ Communication Interface IOD IOD IOD 3
PanelView™ Terminal NA NA NA NA
RSLinx™ Software NA NA NA NA
1769-L20, -L30 Controller with 1761- NET Interface NA NS NS NA
1769-L32E, -35E NA NA IOD NA
1769-L32C, -35CR NA IOD NA NA
1769 CompactLogix™ Communication Interface IOD NA NA 3*
SoftLogix5800™ Communication Interface IOD IOD IOD 3*
PC with RSLinx Only NS NS NS NA
FlexLogic™ Communication Interface IOD IOD IOD 3
IOD = I/O Data
NS = Not Supported
NA = Not Applicable
3 = Requires third party scanner module
* Hilscher North America
Communication Considerations
Serial Bus features are impacted by your network choice.
Network Impact
DeviceNet™ RPSSCDM12A and
RPSSCDM18PA
The RPSSCDM12A and RPSSCDM18PA provide two means of connecting a node of I/O to
DeviceNet™.
A total of 63 Serial Bus modules can be assembled on a single DeviceNet™ node.
Expansion power supplies may be used to provide additional PointBus backplane current.
ControlNet™ RPSSCCNA
A total of 63 Serial Bus modules can be assembled on a single ControlNet™ node.
Expansion power supplies may be used to provide additional PointBus backplane current.
Up to 25 direct connections and 5 rack connections are allowed.
EtherNet/IP™ RPSSCENA
A total of 63 Serial Bus modules can be assembled on a single EtherNet / IP node.
Expansion power supplies may be used to provide additional PointBus backplane current.
Refer to the User Manual, Bulletin 601 (form #A10311) to determine the ratings for direct and rack
connections allowed.
PROFIBUS DP™ RPSSCPBA
A total of 63 Serial Bus modules can be assembled on a single PROFIBUS node.
Expansion power supplies may be used to provide additional PointBus backplane current.
Serial Bus System
